Excellent Brightness and Sharp Imaging BX53 Biological Microscope Featuring LED
with High Luminosity and Color Rendering Performance Simultaneous Launch of 40X Objective Lens for Thick Samples

June 1, 2017

---

Olympus Corporation (President: Hiroyuki Sasa) announced today the progressive international launch of the BX53 biological microscope, featuring Olympus' new high luminosity LED with excellent color rendering performance to provide bright, sharp and true-to-color images.

Designed for high reliability and ease of use, the BX3 series is the flagship in Olympus' range of biological microscopes. An extensive line up of models are available to suit different user needs, ergonomic models ideal for routine work in clinical laboratories to fully-automated instruments necessary for cutting-edge life science research.

With the BX53, users experience the brightness and color reproduction of a 100-watt halogen lamp in a long-life, low-maintenance LED illuminator. Bright and sharp images can be obtained without the need for additional neutral density or daylight filters. The BX53 has been redesigned for easier operation, with an integrated Light Intensity Manager for specifying a preset brightness for each lens that eliminates the need to make adjustments when switching between objective lenses to change brightness levels. Simultaneously, a new 40X objective lens will also be launched to support more precise observations of thick samples such as cytologic smears.

Launch Overview

Name	Launch Date
BX53 biological microscope	June 1, 2017
LPLN40X objective lens with correction collar	June 1, 2017

Main Features

[BX53]

• Excellent brightness and sharp imaging using Olympus' own LED with high luminosity and color rendering performance
• Light Intensity Manager controls customized LED brightness for each objective lens

[LPLN40X]

• Clear observation of thick samples

Launch Background

Recent years have seen an increased interest in fields such as regenerative medicine, resulting in larger sample volumes and an increased demand for the ability to make observations with greater ease and efficiency. This has led to the need for microscopes that help reduce user workloads by providing sharp images of stained samples quickly. The BX53 biological microscope featuring Olympus' LED light source with high luminosity and color rendering performance was introduced to meet this demand.

Details of Main Features

[BX53]
1. Excellent brightness and sharp images using Olympus' LED with high luminosity and color rendering performance

With the BX53, users experience the brightness and color reproduction of a 100-watt halogen lamp in a long-life, low-maintenance LED illuminator. The high luminosity LED can be used to configure a multi-head discussion system¹ for up to 26 people², intended for use in situations such as conferences or classrooms. Moreover, the LED with high luminosity and color rendering performance introduced from this new model is suitable for all forms of transmitted light observation³, including brightfield, darkfield, and polarized light.

2. Brightness can be automatically selected with each objective lens

The BX53 microscope includes a function for specifying a preset brightness for each objective lens. The Light Intensity Manager uses information from a coded revolving nosepiece to adjust to a preset LED brightness level for each objective lens. This helps ensure that users can make observations using their preferred brightness, without the need to make adjustments when switching between objective lenses.

[LPLN40X]
Clear observation of thick samples

Aberrations (image distortion) can occur when observing thick samples at high magnification. The new LPLN40X objective lens with correction collar can correct aberrations to provide clear images regardless of preparation thickness.

Main Specifications of BX53

Optics	UIS2 optical system (infinity-corrected)
Revolving nosepiece	Incorporates readout function
Condenser	Abbe condenser

Olympus's Scientific Solutions Business
The business' product line includes optical microscopes and industrial videoscopes as well as nondestructive testing equipment. Through these products, the Scientific Solutions Business helps to keep the infrastructure of society safe and secure, including research and development in the medical, life science, and industrial fields; quality improvement at production facilities; and inspections of aircraft and other assets.

1 A system enabling a large number of people to simultaneously observe the same field of view.

2 Previous models supported simultaneous observation by up to 10 users only.

3 Brightfield, polarized light, phase contrast, darkfield, and differential interference observation techniques.
